11.2 Brief operating instructions
Functional and operating elements:
1
LSC
plus
user interface
2 Vacuum pump
3 Oil mist separator
Fig. 74:
Front of the freeze-dryer
4
Touchpanel
Fig. 75:
User interface with
touchpanel
