Martin Christ Delta 2-24 LSCplus - Manual (Page 92)

Delta 1-24 LSC&
Delta 2-24 LSC&
10 Technical data
92
Version 04/2013, Rev. 1.2 of 20/02/2014 • sb
Translation of the original operating manual
Pos: 221 /20 0 Ch rist/3 61 G T-BA L abo r-Pilot (PROJEKTE)/Del ta 1 -24 _2- 24 LSC plus/1 00 Tech nische Date n/1 00 Tec hnisch e Dat en Delt a 1 -24/ 2-2 4 LSCpl us= === == == === == == === == == == === == == == @ 15\ mod _13 554 812 096 09_6 8.d ocx @ 781 02 @ 1 @ 1
10 Technical data
Manufacturer: Martin Christ
Gefriertrocknungsanlagen GmbH
An der Unteren Söse 50
37520 Osterode
Germany
Type: Delta 1-24 LSC
plus
Delta 2-24 LSC
plus
Part number: 102300 102301
Performance data Delta 1-24 LSC
plus
Delta 2-24 LSC
plus
Ice condenser
- capacity:
- performance:
- temperature:
- chamber volume:
24 kg max
18 kg / 24 h max
approx. –55°C
approx. 45 l
24 kg max
18 kg / 24 h max
approx. –85°C
approx. 45 l
Temperature of the ice condenser
during hot-gas defrosting:
approx. 60°C
approx.60°C
Possible shelf temperatures
( process A): freezing and drying
inside the ice condenser chamber
approx. –40°C to +60°C approx. –55°C to +60°C
Possible shelf temperatures
( process B): drying outside the
ice condenser chamber
Room temperature to +60°C
Room temperature to +60°C
Max. shelf surface area
( process A):
- drying inside the ice condenser
chamber
- drying in injection vials with
sealing under vacuum or nitrogen
atmosphere inside the ice
condenser chamber
10 shelves, 200 mm each
A
total
=0.31 m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
10 shelves, 200 mm each
A
total
=0.31 m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
Max. shelf surface area
( process B):
- drying outside the ice condenser
chamber
- drying in injection vials with
sealing under vacuum or nitrogen
atmosphere outside the ice
condenser chamber
- drying in round bottom flasks or
wide-neck filter bottles,
max. number
10 shelves, Ø 375 mm each
A
total
=1.1m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
12 pieces, 24 pieces, or 36 pieces
10 shelves, Ø 375 mm each
A
total
=1.1m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
12 pieces, 24 pieces, or 36 pieces
