5 Set-up and connection
Pos: 91 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /05 0 Aufstell ung und Anschlus s/05 0-0 010 Aufst ellort (Alpha -Delt a) @ 6\m od_ 129 913 709 511 0_6 8.docx @ 3 489 4 @ 2 @ 1
5.1 Installation site
Operate the freeze-dryer only in closed and dry rooms.
• The table must be stable and have a solid, even tabletop.
• Ensure sufficient ventilation. Do not place any paper, cloth, or similar
material behind or under the unit, since otherwise the air circulation will
be impaired.
• Keep a safety distance of at least 30 cm from the wall so that the vents
in the unit remain fully effective.
• The ambient temperature must be in the range of +10°C to +25°C.
• Do not subject the freeze-dryer to thermal stress, e.g. by positioning it
near heat generators.
• Avoid direct sunlight (UV radiation).
Pos: 92 / 010 Unive rsalm odul e/ L ee rzeile @ 0\ mod _120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 93 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /05 0 Aufstell ung und Anschlus s/05 0-0 020 Ene rgiev erso rgu ng- -- --- --- -- --- -- --- --- -- --- -- --- -- --- -- @ 6\ mod _129 913 713 915 6_6 8.doc x @ 3 499 8 @ 2 @ 1
5.2 Power supply
Pos: 94 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Delt a 1- 24_ 2-2 4 LSCpl us/05 0 Aufst ellung un d Anschl uss/0 50- 0020 -0 010 Anschlu ssart Delta @ 1 5\mo d_1 355 394 931 251 _68. docx @ 76 834 @ 3 @ 1
5.2.1 Connection
DANGER
The operating voltage on the name plate must correspond to the local
supply voltage!
WARNING
Work on the power supply system must only be performed by certified
electricians.
CHRIST freeze-dryers are units of safety class I. The freeze-dryers of the
type Delta 1-24 LSC
plus
and Delta 2-24 LSC
plus
have a five-wire power
cord with a 5-pin Cekon-plug (see chapter 10 - "Technical data").
CAUTION
Prior to connecting the unit to the power supply system, check the rotary
field at the electrical outlet with a suitable measuring instrument:
The rotary field must be clockwise!
Pos: 95 / 010 Unive rsalm odul e/ L ee rzeile @ 0\ mod _120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 96 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /05 0 Aufstell ung und Anschlus s/05 0-0 020 -00 20 Sic her unge n b auseits @ 6 \mo d_1 299 1371 398 43_ 68.d ocx @ 350 14 @ 3 @ 1
5.2.2 Customer-provided fuses
Typically, the freeze-dryer must be protected with 16 Amp G fuses that are
to be provided by the customer.
