MACHINE NOMENCLATURE
In this Manual, numbers in brackets – for example: (2) - refer to the components shown in the nomenclature pages. Refer to
these pages whenever it is necessary to identify a component mentioned in the text.
1. Control panel
2. [S] Charged battery warning light (green)
3. [S] Half-discharged battery warning light (yellow)
4. [S] Discharged battery warning light (red)
5. Brush/pad switch
6. Vacuum switch
7. Serial number plate/technical data/EC certification
8. Handlebar
9. Handlebar inclination adjusting knob
10. Solution flow control lever
11a. Solution flow control lever ECO position (water
“economy” usage, for a washing autonomy of 70-80
minutes).
11b. Maximum solution flow
11.
12. Recovery water tank cover
13. Rear support wheel for transport/parking
14. Central wheels on fixed axle
15. Brush/pad-holder with pad
16. Brush/pad-holder deck
17. Squeegee
18. Squeegee fixing handwheels
19. Front squeegee blade
20. Rear squeegee blade
21. Squeegee blade fixing springs
22. Recovery water drain hose
23. Recovery water drain hose bracket
24. Solution drain valve
25. Squeegee lifting/lowering lever
26. Solution filter
27. [S] Battery charger-electrical mains connecting
cable (optional)
28. [E] Power supply cable
29. Squeegee vacuum hose
30. Transport/parking device
30a. Transport/parking device activated
30b. Transport/parking device deactivated
31.
32. Transport/parking device positioning pin
33. [S] Electrical component box
34. [S] Battery charger (optional)
35. [S] Battery charger warning lights (optional)
36. [S] Battery installation diagram
37. [S] Battery connector (models without on-board
battery charger)
38. Brush/pad-holder support (activated)
39. Recovery water tank
40. Solution tank
41. Compensation hole
42. Recovery water tank cover (open)
43. Recovery water tank cover gasket
44. Recovery water tank
45. Solution tank
46. Brush/pad-holder support (activated)
47. Vacuum grid with automatic shut-off float
48. Recovery water drain hole
49. Vacuum system motor
50. Brush/pad-holder motor
51. [S] Batteries
52. [S] Battery installation diagram
53. Brush/pad-holder deck
54. Machine speed adjustment screw
55. Brush
56. Pad-holder
57. Pad
58. Right deck fastening screw
59. Left deck fastening screws
60. [E] Terminal board box
61. Cover stand (applied)
[S]: Installed on RAZOR SV 17
[E]: Installed RAZOR E 17
