SERVICE MANUAL
SOLUTION SYSTEM
12
909 6577 000(1)2006-02
SOLUTION SYSTEM
SOLUTION TANK CLEANING
[RAZOR SV 17 - RAZOR E 17]
1.
Drive the machine to the appointed disposal area.
2.
Check that the switches (5 and 6) are turned to “0”.
3.
If necessary, empty the tank (44) by means of the valve (24).
4.
Wash the tank (44) with clean water, then drain the water from the tank by means of the valve (24).
SOLUTION FILTER CLEANING [RAZOR SV 17 - RAZOR E 17]
1.
Check that the switches (5 and 6) are turned to “0”.
2.
Empty the solution tank (44) by means of the valve (24).
3.
Remove the transparent cover (A) and the filter strainer (B), then clean and reinstall them on the support (C).
[The figure shows RAZOR E 17]
S301390
NOTE
The filter strainer (B) must be correctly positioned on the housing (C) of the support (C).
