Item Description Illustration
TP52/TC11-1.8M
1 pcs of power cable European Type F “Schuko” to IEC.
Length 1.8m
Note: Only applicable for factory delivered units with AC Power Input
EUR TYPE F
IEC
TP11/TC11-1.8M
1 pcs of power cable US Type B plug to IEC.
Length 1.8m
Note: Only applicable for factory delivered units with AC Power Input
US TYPE B
IEC
FCE17-E2W2SS-2N0 &
L17DPPK09JSU (cover)
1 pcs of DC Power Input housing with internal cable screw terminal.
Note: Only applicable for factory delivered units with DC Power Input
DV02-SK
1 pcs of DVI > RGB/VGA adapter
DVI 12+5P Male to DSUB 15P Female
MEDIA STD01
Documentation and Driver DVD for factory installed components like mainboard, IDE,
network etc.
Note: To use this DVD disc you will need an external USB CD/DVD drive or provide
means of getting contents copied over via USB memory stick/network to the operating
system. You can alternatively download the drivers from our website www.hatteland-
display.com
Menu browser for
Microsoft®
Windows®
Operating Systems
HT 00226 OPT-A1
Mounting brackets incl. screws (for console mounting)
Test Reports papers:
1 pcs of Product Declaration
1 pcs of Computer Checklist
1 pcs of BurnInTest Certificate
Package may also include: (based on accessories/options ordered)
Item Description Illustration
Terminal Block Connector Kit
Depending on factory mounted options, connector kit as follows (incl. cover hood/cable housing):
4 x 4-pin Terminal Block 3.81 (Weidmüller 1792970000) for CAN Interface (HT 00254 OPT-A1)
+ 4 x Cover Hood (Weidmüller 1005290000 - BCZ 3.81 AH04 BK BX (4-pin)
4 x 5-pin Terminal Block 3.81 (Phoenix 1827732) for RS-422 / RS-485 NMEA COM (PCA100293-1)
+ 4 x Cable Housing (Phoenix 1834372 - KGG-MC 1,5/ 5 (5-pin)
4 x 5-pin Terminal Block 3.81 (Phoenix 1827732) for Digital Input/Output (HT 00268 OPT-A1)
+ 4 x Cable Housing (Phoenix 1834372 - KGG-MC 1,5/ 5 (5-pin)
?
For computers that include 3rd party hardware; the package / accessories box may also include
additional CD / HW / Information from 3rd party supplier(s).
Contents of package
Note: Entries listed below are for Standard factory shipments. Customized factory shipments may deviate from this list.
