General Installation Recommendations
Installation
Air Filter removal / replacement (M153S30Q20-ACC0015) - Alternative #1
Note: Areas of interest are marked in this section with circles and arrows in RED color. Please disconnect ALL
cables from the computer unit and cards before proceeding!
1: Unscrew 4 screws from the fan/filter cover in front of
the unit. Use a Pozidriv #2 screwdriver.
2: Gently pull out the fan/filter cover.
3: Gently pull out the Air Filter from the Air Filter Bracket. Either clean or replace it. (spare part available).
Repeat the procedure backwards to finalize operation.
