Physical Connections

IND100133-56

Factory Preset COM Port Numbering

Hatteland Display offer a wealth of options resulting in many Operating System numbered COM ports. The table

below lists all known ports that are assigned if a specific factory option (or duplicates of them) were factory mounted

prior to manufacturing and delivery of units to customer. Internal on-board, PCI based cards and Modules are listed.

The numbering are only applicable for COM Ports, and not other ports, such as network RJ-45.

Color codes are referring to indications from previous page.

COM Port # On-board/factory option Description

RS-232

Onboard

RS-485/422

Onboard

Intel AMT

Onboard, Intel Active Management Technology 9.0

7-10

CP114UL-I

PCI Card, Serial Communication COM 4 Ports Isolated, RS-232/422/485

11-18

CP-118U-I

PCI Card, Serial Communication COM 8 Ports Isolated, RS-232/422/485

HT 00268 OPT-A1

Digital IO Isolated, 4 Output + 4 Input Module

HT 00254 OPT-A1

CAN isolated, 2 channel Module

21-24

25-28

PCA100294-1 - Card #1

PCA100294-1 - Card #2

COM non-isolated RS-232, 4 channel Module

41-44

45-48

49-52

53-56

PCA100293-1 - Card #1

PCA100293-1 - Card #2

PCA100293-1 - Card #3

PCA100293-1 - Card #4

4 x RS-422/RS-485 NMEA Isolated / ECDIS Module
