General Installation Recommendations
Installation
Air Filter removal / replacement (M153S30Q20-ACC0015) - Alternative #2
Note: Areas of interest are marked in this section with circles and arrows in RED color. Please disconnect ALL
cables from the computer unit and cards before proceeding!
1: Remove cabinet cover (see beginning of this
chapter). When cabinet cover is off, unscrew 1 screw
on top which keeps the Air Filter Bracket in place.
Use a Pozidriv #2 screwdriver.
2: Gently pull/slide out the Air Filter Bracket as indicated.
3: Gently pull out the Air Filter away from the Air Filter Bracket. Either clean or replace it (spare part available).
Repeat the procedure backwards to finalize operation.
