Power ON: To turn the unit on, press down the power button and release it when the symbols are illuminated.
Power OFF: To turn the unit off, press and hold the power button down for 3 seconds. All illuminated symbols will be turned off.
BACKLIGHT LUMINANCE ADJUSTMENT:
The unit features a 100% dimmable image, which means it is capable of displaying a completely black image when
BRIGHTNESS is adjusted fully down to 0%. Also, all the illuminated symbols will fade accordingly based on the
brightness adjustments.
ASSIGNABLE HOT KEYS:
The user can assign various display functions as hot keys. This will enable the user to quickly adjust the brightness,
image size, contrast or other functions to control the image. To assign these hot keys, enter the “UTILITIES MENU /
DIRECT ACCESS” menu and change them to the desired hot key function. The hot-key function is only applicable for
the “UP/DOWN” buttons.
Operation
User Controls
Power Button
+/- Buttons = Luminance Adjustment/Menu Adjustment Buttons
Up/Down Menu Navigation/Hotkey Buttons
START-UP:
The unit features a Instant-ON / Delay-OFF functionality, which ensures that it is not turned off by user accident. The
location is on the right bottom side of the unit together with the other user controls as illustrated below. Note that all
symbols are illuminated from behind as a white/yellowish dimmed color. Ensure that the power switch at rear is set to
the ON position first.
MENU Access
