General Installation Recommendations
Installation
General mounting instructions
1: The useful life of the components of all Electronics Units generally decreases with increasing ambient temperature;
it is therefore advisable to install such units in air-conditioned rooms. If there are no such facilities these rooms
must at least be dry, adequately ventilated and kept at a suitable temperature.
2: This device is cooled by air flowing across the rear cover and air flowing through the ventilation holes. The cooling
must not be impaired by partial covering of the unit or by installation of the unit in a confined cabinet.
3: Units which are to be used on the bridge wing must be installed inside the “wing control console” protected against
the weather. In order to avoid misting of the viewing screen, a 25 ... 50 W console-heating (power depending on the
volume) is recommended.
4: When selecting the site of a display unit, the maximum cable lengths have to be considered.
5: The impairment of read-out from a display screen by direct light from lamps or the sun must be avoided. Rear
windows must be blacked out by means of roller blinds or Venetian blinds.
6: Disturbing reflections on the screen of a display caused by pilot lamps and illuminated signs must be prevented by
suitable measures (screening or relocating).
7: When a product is being installed, the surface base or bulkhead must be checked to ensure that it is flat in order to
avoid twisting of the unit when the fixing screws are tightened, because such twisting would impair mechanical
functions. Any unevenness should be compensated for by means of spacing-washers.
8: Transportation damage, even if apparently insignificant at first glance, must immediately be examined and be
reported to the freight carrier. The moment of setting-to-work of the equipment is too late, not only for reporting the
damage but also for the supply of replacements.
9: The classification is only valid for approved mounting brackets provided by Hatteland Display. The unit shall be
mounted stand-alone without any devices or loose parts placed at or nearby the unit. Any other type of mounting
might require test and re-classification.
