General Installation Recommendations
Installation
Cable Entries & Connectors (Marked area) - Illustration only
Rear View
AC Model illustrated. Explanations for the connectors is available in the “Physical Connections” chapter in this manual.
Maximum Cable Length
The RGB/DVI cable should generally be kept as short as possible to provide a high quality output on the display. The
maximum cable length will depend on the signal resolution and frequency, but also on the quality of the signal output
from the computer. Recommended is 60Hz vertical frequency.
Cables up to 10 meters generally provides good picture quality even with a 1600x1200 (UXGA) 60Hz signal. In most
cases (especially with lower resolutions) even longer cables will provide a satisfactory result. This should however be
tested prior to installation to determine the most suitable distance between signal source and display unit.
