OSD video overlay display function
First Person View (FPV): FY-41AP has an integrated OSD video overlay system, so
you do not need to connect an external video overlay module. The flight data overlays to
video output and through the video transmission system to send back the signal, letting
you enjoy the fun of FPV. And operating FPV is even easier with the functions of
automatic balance, Hovering, and Auto Return To Launch.
FY-41AP Configuration
NO. Module Introduction
1
FY-41AP module
Size: 58mm*37mm*19mm
Weight: 34g
2
GPS receiver module
Size：32mm * 32mm * 13.5mm
Weight：24g
3
Integrated with the Current Sensor and regulating voltage module
to provide stable +12V to the FPV video camera and transmitter at
the same time.
Size：50mm*24mm*18mm
Weight: 35g
4
Use for supporting the GPS module
length：85mm
Weight:9g
5
For FY-41AP firmware upgrade
For connect data link to PC
For connect remote adapter to PC
