GPS module install
 GPS receiver module has integrated plate type GPS passive
antenna with stronger reception ability shielding the false signal
by ground reflection efficiently. DO NOT install next to metal or carbon fiber & other
shielding material, which may block satellite signal reception. Install the GPS Module
horizontal and away from electromagneti c sources such as ESC‘s, power wires, servo
wires & video transmitters which can interfere with GPS signal.
 GPS module should be placed as far as possible to the center position, in order to reduce
the interference to GPS data when it level rotating. Also you can put the GPS module to a
high place using a stent. This practice can effectively reduce the interference to GPS
signals caused by other devices, and improve the positioning performance of GPS module.
Arrow forward（default direction）
Arrow towards to left Arrow towards to right
Arrow towards to back
Nose of the plane
