After each setting, do not forget the " Save parameters "
Camera Gimbal Stabilization adjust instructions
Attention: Please do not adjust the Camera Gimbal Stabilization until you have finished
the multi-rotor aircraft adjust.
Please according to following steps to adjust Camera Gimbal Stabilization :
(1) Gimbal Reverse
1) Shaking the Camera Gimbal on roll direction , if 41AP doesn‘t give the
corresponding reverse correction, please choose Roll reverse.
2) Shaking the Camera Gimbal on pitch direction , if 41AP doesn‘t give the
corresponding reverse correction, please choose pitch reverse.
(2) Gimbal Gain
The default Gimbal Gain:Roll 50,Pitch 50.
Under the condition of servo no rotation, you should control the camera gimbal with the
RC stick. If the servo is shaking when the stick in the neutral position, that‘s indicates the
sensitivity is too much. As a result, you should slowly decrease (10% -20% each time)
corresponding direction Gimbal Gain, until the shaking situation disappears. If the camera
gimbal goes back to Neutral, it is too soft. As a result, you should slowly increase (10%
-20% each time) corresponding direction Gimbal Gain
(3) Gimbal Neutral
The default Gimbal Neutral is 1520.
Power on and put the camera gimbal into level position, observe the servos position. If
the servos is not in the Neutral value, please thoroughly adjust the corresponding servos
Gimbal Neutral to put them into Neutral value position.
Adjusting method: According to corresponding servo reaction, appropriate increase or
decrease corresponding servo Gimbal Neutral.
