Guilin Feiyu Electronic Technology Co., Ltd

Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn [email protected]

- 20 -

Motor Mixer

The following pictures display the rotation direction and serial number of each

motor, each ESC should be connected to the DoS&41AP S1 - S8 interface. Pay
attention that once you‘ve chosen the control type, the corresponding position motor
rotation direction has to be completely the same as in the picture. (If the motor rotation

direction is not correct then exchange any two of the three connect wires between ESC

and motor to change the motor rotation direction.)

FY-41AP support the following types of multi-rotors:

FY-41AP Setting and Debugging

After FY-41AP system has been installed and connected, you can adjust settings for

the FY-41AP, follow the steps below.

Direction Setting

First of all, according to the direction of

the FY-41AP installation set direction.
