Auto CQ/Video-DSL Rate Prediction
Copper Test Module 57
Running Video-DSL Rate Prediction Tests and Viewing Results
³
Technology lists the following values: ADSL2+, ADSL2, or ADSL. If
Annex L is previously selected, ADSL2 is automatically set. If Annex M,
ADSL is not available.
³
Recalculate button allows you to change the setup and re-evaluate the
rates.
To re-set parameters to view different results:
1. Press the up/down or left/right arrow keys to highlight the desired
parameter.
2. Press to display the list or select the value.
3. Press the up/down arrow keys to highlight the desired value.
OR
4. Press the left arrow key to erase the existing value, and then use the
alphanumeric keypad to enter a value. To cancel the entry, press .
5. Press to accept the value.
6. Press the up/down arrow keys to highlight the Recalculate button.
7. Press to recalculate rates for the new setup.
