Getting Started with Copper Qualification Tests
Copper Test Module 21
Reading Saved Results
³
WB Impulse Noise
³
WB Impulse Noise Histogram
³
Spectral Detective
³
PSD Noise
³
Attenuation
³
WB Longitudinal Balance
³
WB Data Rate Prediction
³
Rect. L Detection
³
Resistive Balance
To open previously saved test results:
1. Press
to open the list.
2. In the list, press the up/down arrows to select the test type.
3. Press to confirm the selection.
4. Press the down arrow to activate the Result Files list box and
press to display the list of available files.
5. Press the up/down arrows to select the desired result file.
6. Press to view the selection.
