Upgrading The Computer
6 - 22 Upgrading the Video Card
6
7. Remove screws & from the video card (two video cards are pictured).
8. Carefully remove the video card .
9. If your system includes two video cards you will need to disconnect the cable
between the master and slave cards (do not forget to reconnect the cable if you
are replacing two cards).

Caution
The heat sink, and video
card area in general,
contains parts which are
subject to high tempera-
tures. Allow the area
time to cool before re-
moving these parts.
Figure 6 - 24
Video Card Removal
12 13
14
15
14 14
12 13 12 13
15
