1 - 6 System Map: LCD Panel Open

Quick Start Guide

1

System Map: LCD Panel Open

Figure 1 - 2

LCD Panel Open

1.

Built-In PC Cam-
era

2.

PC Camera LED

3.

Built-In
Microphone

4.

LCD

5.

Power Button

6.

LED Indicators

7.

Keyboard

8.

Touchpad &
Buttons

9.

LED Indicators

3

5

1

7

8

4

2

6

Wireless Device

Operation Aboard

Aircraft

The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the WLAN/
Bluetooth/3G
modules
are OFF if you are using
the computer aboard air-
craft.

Use the Airplane Mode
hot key combination to
toggle Airplane Mode
On/Off, and check the
LED indicator for the
power status.

9
