Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 11
6
Reinserting the Hard Disk
1. Reverse the process to install a new disk and do not forget to reinstall the cover
and screws (see
Figure 6 - 6 on page 6 - 10 ).
2. Place the hard disk assembly into the bay and slide it in the direction of arrow .
3. Replace the component bay cover (see page 6 - 8 ).
Figure 6 - 7
Inserting the Hard
Disk
1
5
1
