Eurocom M3 - Manual (Page 129)

Upgrading The Computer
Removing the Component Bay Cover 6 - 7
6
3. Lift the cover up at point and remove the cover the direction of arrow .
Figure 6 - 4
Component Bay
Cover Removal
4 5 6
4 5
6

Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upgrade, remember
to replace the cover(s) and screw(s) before turning restoring power to the system.
Also note the following when the cover is removed:
• Hazardous moving parts.
• Keep away from moving fan blades.
• Do not touch the heat sink area as the parts may be hot.
