Elenco Snap Circuits SnapMicro I Deluxe ® - Manual (Page 41)

40
debug
Syntax:
DEBUG {var}
- Var is an optional variable value (e.g. b1).
Function:
Display variable information on computer in Debug Window
The debug command uploads the current variable values for all the
variables via the download cable to the computer screen. This enables
the computer screen to display all the variable values in the micro-
controller for debugging purposes.
Note that the debug command uploads a large amount of data and so
significantly slows down any program loop.
1. Make the flowchart shown on left.
2. Use PICAXE drop down menu to convert to basic
3. Edit program for clarity.
4. Go to next page for notes on running the program.
