Network XML Programmer’s Guide
39
assumed.
Value/ Dimension/
NumberElements
Y
Y
Applies to array values. Specifies the number of
elements in the current dimension. On import,
this value must be specified, and it must be
greater than 0.
Example
NETWORK6:Subsystem1
Channels
Attributes
Attribute
Applicable
Values
Description/Notes
Action
1 IGNORE
2 CREATE
3 CREATE_UNIQUE
4 UPDATE
5 MODIFY
6 DELETE
7 COMMISSION
To create a channel, you must specify the
Channel Name and TransceiverID properties.
Properties
Supported by
Function?
Property
Export Import
Description/Notes
Name
Y
Y
The channel name is reported.
TransceiverId
Y Y An
enumerated value indicating the channel
type. The ID attribute is the transceiver ID as
reported by LNS. The value is the transceiver
name as determined in the StdXcvr.XML file.
The possible values are as follows:
3
TP/XF-1250
1
TP/XF-78
5
TP/RS485-39
7
RF-10
9
PL-10
4
TP/FT-10
16
PL-20C
17
PL-20N
18
PL-30
12
TP/RS485-78
10
TP/RS485-625
