L
ON
W
ORKS
Network XML Programmer’s Guide
17
Example
Routers
Attributes
Attribute
Applicable
Values
Description/Notes
Action
1 IGNORE
2 CREATE
3 CREATE_UNIQUE
4 UPDATE
5 MODIFY
6 DELETE
7 COMMISSION
If you are creating a router, you must specify the
Name property and specify the channels
attached to the router within the
NearRouterSide and FarRouterSide
properties.
If you specify the COMMISSION action, the
router’s Neuron ID and Channel properties are
updated.
Commission
0 False
1 True
You must set this property to True to enable
commission-related operations.
State
0 DEFAULT
1 ONLINE
2 OFFLINE
3 DISABLE
4 RESTORE
You can specify the state of the router
application. The default is DEFAULT, which
indicates the settings of the LNS application are
to be used.
Properties
Supported by
Function?
Property
Export Import
Description/Notes
Name
Y
Y
Routers are reported in the subsystem in which
their shapes are defined. Routers defined in
multiple subsystems are not supported.
LNS requires that router names be unique within
the entire network (not just within a subsystem).
Class
Y Y An
enumerated
value
indicating the router type.
