Using the XML Schema
Selector
Y N Specifies
the
selector used for the NV alias.
Value
Y N To
report
NV
values, you must specify the
Export NV values option (&H10) in the
XMLOptions export automation property (see
Invoking the Export Feature in Chapter 1).
If the NV value cannot be read from the
application device, the text string “?Unknown”
is reported.
HasShape
Y Y An
enumerated
value indicating whether the NV
is represented by a shape on the FB shape in the
network drawing. The possible values are as
follows:
0
False
1
True
You can preserve the NV shape on import by
setting the HasShape property to True
ConnDesc
Y N The
name
of
the
connection description template
used for connections in which the NV is the hub
is reported on export. For unconnected NVs,
ConnectDescTemplate_0 is reported.
ConfigProperties
Y
Y
The NV type CPs of the NV are reported.
Global CPs are reported in the
FunctionalBlocks property. See Configuration
Properties for more information.
Targets
Y Y The
target
NVs
connected to the NV are
reported. See Targets for more information.
