Echelon LonWorks Network XML User Manual
Page 34
26
Using the XML Schema
3
Manf
4
ManfDevClass
5 ManfDevClassSubClass
6 ManfDevType
Virtual functional blocks do not contain this
property.
IsDynamic
Y N An
enumerated
value indicating whether the
functional block is static or dynamic. The
possible values are as follows:
0
False (static)
1
True (dynamic)
IsVirtualFb
Y N An
enumerated value indicating whether the
functional block is a virtual functional block.
0
False (standard functional block)
1
True (virtual functional block)
Shape/StencilName Y Y The
name
of
the Visio stencil containing the
master shape for the functional block. If you do
not specify this property or it is not found on
import, the LonBasic stencil is used.
Shape/MasterName Y Y The
name
of
the master shape for the functional
block. If you do not specify this property or it is
not found on import, the functional block shape
in the LonBasic stencil is used.
Shape/PinX
Y
Y
The X coordinate of the functional block shape
in the Visio page.
Shape/PinY
Y
Y
The Y coordinate of the functional block shape
in the Visio page.
SubsystemName
Y
Y
On export, this value specifies the relative path
name of the subsystem containing the functional
block shape.
If you are creating a functional block, you can
use this property to place the functional block in
a subsystem different from its associated
application device. However, you cannot use
this property to move an existing functional
block from one subsystem to another.
Extensions
Y
Y
Extension records defined for this functional
block. See Extension Records for more
information.
NetworkVariables
Y
Y
The NVs defined on this functional block. See
Network Variables for more information.
MTs
Y
Y
The MTs are only reported for virtual functional
blocks. You can only add MTs on import to a
virtual functional block.
ConfigProperties
Y
Y
The configuration properties defined on this
functional block.
See Configuration Properties for more
