Echelon LonWorks Network XML User Manual
Page 31
L
ON
W
ORKS
Network XML Programmer’s Guide
23
is non-empty.
Priority
Y Y On
export,
the
current value (specified manually
or selected automatically) is reported. There is
no indication of how the value was selected.
On import, LNS will automatically select a
priority slot for the application device if you
specify a value of 255.
AliasCapacity
Y N The
number
of
alias table entries available on
the application device.
AliasUseCount
Y N The
number
of
alias table entries consumed by
the application device.
Shape/StencilName Y Y The
name
of
the Visio stencil containing the
master shape for the application device. If you
do not specify this property or it is not found on
import, the LonBasic stencil is used.
Shape/MasterName Y Y The
name
of
the master shape for the application
device. If you do not specify this property or it
is not found on import, the application device
shape in the LonBasic stencil is used.
Shape/PinX
Y
Y
The X coordinate of the application device
shape in the Visio page.
Shape/PinY
Y
Y
The Y coordinate of the application device
shape in the Visio page.
CommissionStatus
Y
N
An enumerated value indicating the current
device configuration on export. The possible
values are as follows:
0 UpdatesCurrent
1 UpdatesPending
2 UpdatesFailed
AttachmentStatus Y N An enumerated value indicating the whether the
application device is communicating with the
network on export. The possible values are as
follows:
0 Attached
1 InImproperState
2 NotAttached
PingClass
Y Y An
enumerated
value indicating the expected
movement of the application device, which
determines the frequency in which it is pinged.
The possible values are as follows:
0
Default (default ping interval is used)
1
Mobile (1-minute ping interval is used)
2
Temporary (2-minute ping interval is
used)
3
Stationary (15-minute ping interval is
used)
4
Permanent (device is not pinged).
Subnet
Y
Y
The subnet element contains a Handle attribute
which reports the subnet ID. On import, this can
be used to specify the subnet to which the device
