16 Using the XML Schema
NV/message tag target definitions. See Targets
for more information on using subsystem
references.
Properties
Supported by
Function?
Property Export Import Notes
Name Y Y If you are creating a subsystem, you must specify a
name in the subsystem’s Name property that is
unique within the parent subsystem.
DocumentName Y Y If you do not specify this property, the subsystem
will be assigned the same document name as the
subsystem’s parent subsystem. If the subsystem is
at the root of a document, the subsystem will be
assigned a document name that is the same name as
the network.
If the network name specified in the file matches
the beginning of the specified document name, the
name of the current network will be used.
The maximum document name length is 80
characters.
PageName Y N On import, a unique page name (within the
subsystem’s document) is assigned based on the
subsystem name.
Location Y Y The absolute path of the subsystem.
SubsystemID Y N An integer value corresponding to the lower 15 bits
of the LNS handle assigned to the subsystem.
Shape/StencilName Y Y The name of the Visio stencil containing the master
shape for the Subsystem shape. If not specified or
not found, the LonBasic stencil is used on import.
Shape/MasterName Y Y The name of the master shape for the Subsystem. If
not specified or not found, the Subsystem shape in
the LonBasic stencil is used on import.
Shape/PinX Y Y The X coordinate of the Subsystem shape in the
Visio page.
Shape/PinY Y Y The Y coordinate of the Subsystem shape in the
Visio page.
Description Y Y The optional user-provided description for the
subsystem.
AppDevices Y Y The application devices within the subsystem. See
Application Devices for more information.
Routers Y Y The routers within the subsystem. See Routers for
more information.
Subsystem Y Y A subsystem nested within the subsystem.
Extensions Y Y Extension records defined for this subsystem. See
Extension Records for more information.
