DaySequerra M4FM - Manual (Page 3)

3
M4FM User Manual
Table of Contents
Important Safety Information 4
Service Information 4
Introduction 5
M4FM Key Features 6
M4FM Technical Specifications 7
Unpacking and Installing 8
Operating Description - Controls and Indicators 9
Front Panel 9
Rear Panel 10
LCD Display 11
Modulation Measurements 12
System Menu 13
WebServer 19
Restore Factory Settings 25
Three Year Warranty 26
All rights reserved DaySequerra Corp. Copyright 2009.
All logos and trademark used herein are the property of their respective owners.
Specifications subject to change.
M4FM
M4FM – Features
• Frequency-Agile RF Input – Synthesized FM preselector provides -50 dB
quieting sensitivity < 30 dBf (-90 dBm)
• Built-in RF Attenuator – 30 dB for wide RF input range of <0.5 vRMS
to 7 vRMS
• Worldwide Capable – Complete with user-selectable 100 or 200 kHz
tuning steps and 50 or 75 µSec de-emphasis
• Simultaneous Modulation Measurements – Total, pilot, L, R, L+R and
L-R, and all Composite-SCA level measurements with better than 1.0%
accuracy
• Superb Audio Performance – +4 dBm @ 100% modulation with SNR >
75 dB and THD < 0.1%; full-time AES-3 digital audio output as well as a
high-performance headphone output with greater than 1W into 8-ohm
• Email Alerts and Rear Panel Alarm Tallies – For loss of Audio, Carrier
and RDS/RBDS; remote reset via rear panel GPI
