Denon DVD-3800 - Manual (Page 29)

29
ENGLISH
STOP
PROGRESSIVE DVD
1 2 9 8
REMOTE SENSOR
OPEN/CLOSE 5
DVD AUDIO
¢ ON / STANDBY
£ OFF
PLAY STOP
7 6 3 STILL / PAUSE
B
PURE DIRECT MODE 1 MODE 2 OFF
AL24 PLUS
DVD AUDIO-VIDEO PLAYER DVD-3800
2 1 1
17 PLAYING STILL PICTURE FILES (JPEG FORMAT)
2 JPEG files stored on Kodak picture CDs, CD-Rs and CD-RWs can be played as a slide show and enjoyed on
the DVD-3800.
1
2
Load the picture CD into the DVD-3800.
• When the disc is loaded, a slide show of the still
pictures begins automatically.
• The slide show continues until the STOP button is
pressed.
Press the STOP button.
• The slide show of the picture CD stops. 2
STOP
Main unit Remote control unit
OPEN / CLOSE
OPEN/CLOSE
5
Main unit Remote control unit
4 5 6
ENTER
ON OFF
REMOTE CONTROL UNIT RC-553
TOP MENU DISPLAY
NTSC / PAL OPEN / CLOSE
CALL RETURN
SKIP SLOW / SEARCH
POWER
ANGLE SUBTITLE AUDIO SEARCH MODE
PLAY
STILL /
PAUSE STOP
1
7
0
2
8
+10
3
9
PROG / DIR
V.S.S.
CLEAR
MENU
1
2
2 Kodak picture CDs can be played on the DVD-3800.
When a picture CD is played, the photographs on the picture CD can be displayed on a TV.
(“Picture CD” is a service by which photographs taken on conventional silver film cameras are converted
into digital data and written on CDs. For details on Picture CD, contact a store that offers Kodak
development services.)
Playing picture CDs
Playing still pictures stored on CD-Rs/RWs
1
Load the CD-R/RW on which the still pictures
have been written into the DVD-3800.
• When the disc is loaded in the DVD-3800, the
disc information screen appears.
• If there are multiple folders proceed to step 2.
• If there are no folders on the disc, proceed to
step 3.
PROGRESSIVE DVD
1 2 9 8
REMOTE SENSOR
OPEN/CLOSE 5
DVD AUDIO
¢ ON / STANDBY
£ OFF
PLAY STOP
7 6 3 STILL / PAUSE
B
PURE DIRECT MODE 1 MODE 2 OFF
AL24 PLUS
DVD AUDIO-VIDEO PLAYER DVD-3800
3 1 1
D I SC I NF ORMATI ON
S I NGL E : DEC I S I ON : ENTER BUT TON
0 ROOT
1 JPEG 1
2 JPEG 2
3 JPEG 3
4 JPEG 4
5 JPEG 5
ROOT
P L AY MODE F OL DE R
S I GNAL E L APSED : - - : - -
B
4 5 6
ENTER
ON OFF
REMOTE CONTROL UNIT RC-553
TOP MENU DISPLAY
NTSC / PAL OPEN / CLOSE
CALL RETURN
SKIP SLOW / SEARCH
POWER
PLAY
STILL /
PAUSE STOP
1
7
0
2
8
+10
3
9
PROG / DIR
V.S.S.
CLEAR
MENU 3
1
2, 3
2
Use the • and ª cursor buttons to select the
folder containing the file(s) you want to play,
then press the ENTER button.
✽ To change the folder
Use the • cursor button to select “ROOT” at
the upper right of the screen, then press the
ENTER button. The screen in step 1
reappears. Select the desired folder.
D I SC I NF ORMATI ON
S I NGL E : DEC I S I ON : ENTER BUT TON
0 • •
1 A
2 B
3 C
4 D
5 E
JPEG 1
JPEG 2
JPEG 3
JPEG 4
JPEG 5
ROOT
P L AY MODE F OL DE R
S I GNAL E L APSED : - - : - -
B
Remote control unit 3
Use the • and ª cursor buttons on the remote
control unit to select the still picture file from
which you want to start the slide show, then
press the PLAY button or the ENTER button on
the remote control unit.
• The slide show starts.
• Only the still picture files in the selected
folder are played.
✽ Once all the still picture files in the folder have
been played, the disc information screen
reappears.
D I SC I NF ORMATI ON
S I NGL E : DEC I S I ON : ENTER BUT TON
0 • •
1 A
2 B
3 C
4 D
5 E
JPEG 1
JPEG 2
JPEG 3
JPEG 4
JPEG 5
ROOT
P L AY MODE F OL DE R
S I GNAL E L APSED : - - : - -
B
Remote control unit
ENTER
Remote control unit
✽ To view several of the still pictures stored on the disc at once:
• Press the MENU button to display up to 9 still pictures at once.
• To select and view a still picture (to start the slide show from a specific still picture), use the cursor
buttons (ª, •, 0 and 1 ) to select the desired still picture, then press the ENTER button.
✽ To temporarily stop the slide show:
• Press the PAUSE button.
• To resume the slide show, press the PLAY button.
✽ To cue a still picture you want to view (from which you want to start the slide show):
• During the slide show, press one of the SKIP ( 8 , 9 ) buttons. Press the SKIP 8 button to cue
back to the previous still picture, the SKIP 9 button to cue ahead to the next still picture.
✽ Flipping and rotating still pictures:
• Use the cursor buttons (ª, •, 0 and 1 ) to flip the still picture.
• cursor button: The currently displayed still picture is flipped vertically.
ª cursor button: The currently displayed still picture is flipped horizontally.
0 cursor button: The currently displayed still picture is rotate 90° counterclockwise.
1 cursor button: The currently displayed still picture is rotate 90° clockwise.
✽ Play the image in the zoom mode.
• When the ZOOM button is pressed while playing a JPEG image (“ZOOM ON” is displayed on the
screen at this time) zoom in and zoom out using the search keys.
(
6 : zoom out, 7 : zoom in)
• When the image is zoomed, use the cursor buttons (ª, •, 0 and 1 ) to move the zoomed picture.
• Continuous playback (SLIDE SHOW) is not possible in the zoom mode.
✽ The way of switching to the next image during continuous JPEG image playback (SLIDE SHOW) can be
selected.
• Press the V.S.S. button on the remote control unit.
• Select from SLIDE SHOW MODE 1 to MODE 11, RAND and NONE.
1
PLAY
Main unit
PLAY
Remote control unit Remote control unit
ENTER
