25
ENGLISH
REFERENCE:
(1) On the gamma correction display, the horizontal axis indicates the
brightness level of the image as recorded on the disc, while the
vertical axis indicates the brightness level of the image when
output from the set.
MEMORY 1 GAMMA
0
0
100
235
(2) When a bright point on the disc side is adjusted to “dark” on the
output side as shown in the diagram at the right, normally the
details of bright sections that are hard to see become easier to
see.
MEMORY 1 GAMMA
0
0
100
235
(3) When a bright point on the disc side is adjusted to “bright” on the
output side as shown in the diagram at the right, normally the
details of dark sections that are hard to see become clearer.
MEMORY 1 GAMMA
0
0
100
235
GROUP 01/02
GROUP ELAPSED TRACK 01 /10
0 : 00 : 01
AUDIO 1/1 : LPCM 2 ch/ 96 kHz/24BIT
GROUP REMAIN 0 : 57 : 59
TRACK ELAPSED 0 : 00 : 01
TRACK REMAIN 0 : 05 : 59
12 USING THE ON-SCREEN DISPLAY
2 Use this function to display and change information on the
disc (titles, chapters, time, etc.)
1
In the play mode, press the DISPLAY button.
• The On-Screen Display appears.
• The picture on the TV screen switches each time the button is
pressed.
• The items displayed differ from disc to disc.
• Normal playback screen
• Disc information screen
• Disc information screen
2
3
Use the • and ª cursor buttons to select the item you wish to
change.
• The selected item is displayed with a yellow frame.
q For DVD audio discs
The elapsed time, etc., of groups and tracks can be
selected.
w For DVD video discs
The elapsed time, etc., of titles and chapters can be
selected.
e For video and music CDs
The elapsed time, etc., of tracks can be selected.
q Changing the elapsed time
Input using the number buttons, then press the ENTER
button.
Example: For 1 minute 26 seconds / “00126”
w Changing the title, track or chapter
• For DVDs
Input using the number buttons, then press the ENTER
button.
(For some discs it is not possible to change the title or
chapter.)
• For video and music CDs
Input using the number buttons. Playback starts from that
track.
ENTER
Remote control unit
TITLE 01/10
TITLE ELAPSED CHAPTER 01 /10
00 : 00 : 01
SUBTITLE OFF
AUDIO 1/2 : DOLBY D3/2.1 ENGLISH
TITLE REMAIN 01 : 10 : 59
CHAPTER ELAPSED 00 : 00 : 01
CHAPTER REMAIN 00 : 40 : 59
• Normal playback screen
• Disc information screen
Example: For DVD video discs
4 5 6
ENTER
ON OFF
REMOTE CONTROL UNIT RC-553
TOP MENU DISPLAY
NTSC / PAL OPEN / CLOSE
CALL RETURN
POWER
PLAY
STILL /
PAUSE STOP
1
7
0
2
8
+10
3
9
PROG / DIR
V.S.S.
CLEAR
MENU
3
1
3
2
2
Remote control unit
DISPLAY
4 5 6
1
7
0
2
8
3
9
Example: For DVD audio discs
• Disc information screen
TRACK 01 / 10
SINGLE ELAPSED
26 : 11
SINGLE REMAIN 03 : 17
TOTAL ELAPSED 06 : 15
TOTAL REMAIN 32 : 05
• Normal playback screen
• Disc information screen
Example: For video and music CDs
Remote control unit
