23
ENGLISH
(8) Using the V.S.S. (Virtual Surround Sound) function (only for DVDs)
During playback, press the V.S.S. button on the remote
control unit. Remote control unit
V.S.S.
2 Using the V.S.S. (Virtual Surround Sound) function gives the sound a sense of expansion and allows you to
achieve surround effects even when only front speakers (left and right) are used. For discs with surround
signals, the V.S.S. function not only gives the sound expansion, it also makes it seem as if sound is coming
from the sides, even though there are no speakers there.
NOTES:
• This function only works with DVDs containing two or more
channels of Dolby Digital signals.
• The V.S.S. function does not work at the time of multi-channel setting.
Set “AUDIO CHANNEL” under “AUDIO SETUP” at “SETUP” to “2
CHANNEL”.
• Note that for some discs the effect will be weak or there will be no
effect.
• For some discs the sound may be distorted. If so turn the V.S.S.
function off.
• Turn off other surround functions (the TV’s surround mode, etc.).
• The effect is best when listening at a distance from the TV equal to
3 to 4 times the distance of the left and right speakers (distance
A).
Distance A
Listening position
3 to 4 times
distance A
Speaker Speaker
(9) Selecting the still image
During playback, press the PAGE + or PAGE - button on the
remote control unit.
• For DVD audio discs with still images, the desired image
can be selected.
• On some discs the image cannot be selected due to the
intentions of the discs’ producers.
PAGE
Remote control unit
(10) Playing bonus groups
In the stop mode, press the SEARCH MODE button on
the remote control unit to set the search mode to
“GROUP”.
1
Use the number buttons to input the bonus group
number.
2
4 5 6
1
7
0
2
8
+10
3
9
Remote control unit
SEARCH MODE
Remote control unit
Use the number buttons on the remote control unit to
input the password (4 digits), then press the ENTER
button.
• Playback starts from the first track in the specified
group.
3
ENTER
Remote control unit
• In some cases the password must be input at the menu screen. In these cases, follow the instructions on
the screen.
• Once the password is input, the disc can be played as many times as you want until it is removed.
• If you make a mistake when inputting the password, press the CLEAR button on the remote control unit.
PROGRESSIVE DVD
1 2 9 8
REMOTE SENSOR
OPEN/CLOSE 5
DVD AUDIO
¢ ON / STANDBY
£ OFF
PLAY STOP
7 6 3 STILL / PAUSE
B
PURE DIRECT
MODE 1 MODE 2 OFF
AL24 PLUS
DVD AUDIO-VIDEO PLAYER DVD-3800
4
10 USING THE PURE DIRECT MODE
2 In the pure direct mode, only analog audio signals (no video signals, etc.) are output, thereby achieving high
quality sound.
1
Press the P.D.MEMORY button on the remote
control unit.
• The output status of the video signals, etc., can be
stored at MODE 1 and MODE 2 as desired.
ENTER
TOP MENU DISPLAY
MARKER RANDOM
PAGE
A-B
ZOOM
DIMMER
REPEAT
SETUP
CALL RETURN
SKIP SLOW / SEARCH
ANGLE SUBTITLE AUDIO SEARCH MODE
PLAY
STILL /
PAUSE STOP
PIC.ADJ
7
0
8
+10
9
P.D.MEMORY
MENU
1, 3
2
SE TUP
SE L EC T : DE C I S I ON : ENT E R BUT TON
PURE D I RE C T MODE
PURE D I RE C T MEMORY
PURE D I RE C T MODE 1
D I G I TAL OUTPUT
V I DEO OUT
D I SP L AY
MODE 1
MODE 2
ON
ON
ON
P.D.MEMORY
Remote control unit
2
Use the • and ª cursor buttons to select the mode,
then press the ENTER button.
DIGITAL OUTPUT
ON: Digital audio signals are output.
OFF: Digital audio signals are not output.
VIDEO OUT
ON: Video signals are output.
OFF: Video signals are not output.
DISPLAY
ON: It is indicate in Display of the main unit.
OFF: It is not indicate in Display of the main unit.
SE TUP
SE L EC T : DE C I S I ON : ENT E R BUT TON
PURE D I RE C T MODE
PURE D I RE C T MEMORY
PURE D I RE C T MODE 1
D I G I TAL OUTPUT
V I DEO OUT
D I SP L AY
MODE 1
ON
O F F
Remote control unit
ENTER
Remote control unit
Press the P.D.MEMORY button on the remote
control unit.
• All of the settings are stored in the memory.
3
Remote control unit
P.D.MEMORY
Switch the PURE DIRECT switch on the main unit.
OFF: All signals are output normally.
MODE 1: The settings stored for MODE 1 are
used.
The factory default settings are:
“DIGITAL OUT”: “ON”
“VIDEO OUT”: “ON”
“DISPLAY”: “ON”
MODE 2: The settings stored for MODE 2 are
used.
The factory default settings are:
“DIGITAL OUT”: “ON”
“VIDEO OUT”: “ON”
“DISPLAY”: “ON”
4
Main unit
PURE DIRECT
OFF MODE 1
MODE 2
