Minimum
Output
“Offset”
Maximum
Output
Point
Output
“Gain”
1.
0"
12"
12"
2.
2"
10"
8"
3.
5"
11"
6"
Minimum
Gain
FIGURE 10
ACCEPTABLE OUTPUT
OUTPUT
BOUNDARIES
ANALOG OUTPUT
VOLTS
50% CYLINDER TRAVEL (IN.)
