< 2.1 > Package Contents
Key Hardware
The equipment comes with the standard parts shown on the package contents. Check and make sure they are included and in good
condition. If anything is missing, or damage, contact the supplier immediately.
Unpacking
Card# 12345678
Each package bundled with smartcard x 1. The card
on the bottom right shows card number information :
Card# 12
Patented and Worldwide
Patents Pending
- X-2000 OR X-1000 InfraBox, 1 pc
- 800 MiFARE OR Proximity smart card handle, pair
- Inductive OR Mechanical door sensor, pair
- Front door cable, 2-section with joint connector, 1 pc ( 3150mm )
- Rear door cable, 2-section with joint connector, 1 pc ( 2350mm )
- 6’ Power cord, 1 pc
- Activated smartcard, 1 pc
- Key, 1 pc
- Cable clip, 8 pcs
X-2000
X-800P X-800M
OR
OR
X-1000
Handle mounting screw set :
- Handle mounting bracket, 2 pcs
- U bracket x 2
- M3 x 10mm screw, 4 pcs
- M4 x 9mm screw, 4 pcs
- M5 x 10mm screw, 2 pcs
- Circle hole washer, 2 pcs
- Square hole washer, 6 pcs
