Austin Hughes X-800 Smartcard Handle - Manual (Page 17)

www.austin-hughes.com UM-X-ISM-Q414V3 P.12
Sensor
area
Present the smartcard and
touch the handle sensor
area for 1 to 2 seconds
Smartcard mode
For smartcard operation,
keep key cylinder always
to
12 o’clock direction.
Key cylinder to 3 o’clock direction
Under key unlock mode, the handle
keeps unlocked.
Key cylinder to 9 o’clock direction
Under key lock mode, even present the
smartcard, the handle still keeps locked.
Key unlock mode
Key lock mode
Under Smartcard mode, always keep key cylinder to 12 o’clock direction.
Important Note for Key lock
Key cylinder to 3 o’clock direction.
Key cylinder to 9 o’clock direction.
Key unlock mode
Key lock mode
Unless the smartcard handle is defective, lock / unlock the handle by key is NOT recommended
Please insert & turn the key with push force
