Application
< 6.1 > Data Center
By mixed connection, InfraSolution X can be scalable up to 3000 cabinets. X-2000 and X-1000 InfraBoxes can be
coexisted in the same network. Users are enabled to manage and remotely access all cabinets under a centralized
and user friendly GUI.
Management PC
Client PCs
Connect the 1st InfraBox in each daisy chain to the network switch
Connect the management PC and client PCs via the network switch
Up to 3000 Infraboxes / Cabinets
