AMT Datasouth M5DT Plus User Manual
Page 18
16
3.8 Internal Ethernet Print Server Module Installation (Option)
1. Break through the plastic partially connected at the rear side of lower cover RJ45
interface opening.
2. Remove the screw from the main board. Fasten the metal and plastic standoff.
Plastic standoff
Metal standoff
RJ45 interface opening
Remove the screw
