APPENDIX B
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe installation
Sidewall:
18 inches measured from the outer door edge hinge
Ceiling:
7 feet from the base of the fireplace
Fireplace Enclosure:
Bottom: 0
Side: 1 inch
Back: ½ inch
Top: 2 ½ inches. Header may rest on top of top spacer.
NOTE:
Combustible material cannot be used in the space directly above the fireplace.
Mantel: Ducts closed with top grill open 71 inches
Mantel:
With 31/2 inches brick on front 59 inches
Mantel:
Ducts open & top grill open 55 inches
Mantel:
Ducts open & top grill closed 45 inches
Hearth:
Fireplace Width (42 + 8 + 8) 58 inches
Hearth:
Depth from front of fireplace 24 inches
NOTE: Mantel measurements are from the bottom of the Inglenook Fireplace unit.
