25
greatly reduce the amount of maintenance required.
CLEANING INSTRUCTIONS…continued
WARNING: DISCONNECT THE POWER CORD BEFORE CLEANING OR SERVICING THIS UNIT.
THE STOVE MUST BE TURNED OFF AND COOLED BEFORE USING THE RAKE HANDLE.
I. HEAT EXCHANGER:
This stove is designed with a built-in heat exchange tube
Rake. The ash handle is located on the front of the s
and is moved backwards and forwards several times
to remove the buildup of ash. After cleaning, push t
rake handle in until it stops.
II. COMBUSTION BLOWER:
Over the course of the heating season dust and ash may collect on the blades of the combustion blower.
Periodically they should be inspected and vacuumed clean. The combustion blower is accessed by opening the
stove’s right side panel and then removing the inspection caps or the exhaust manifold cover (See figure below).
Never operate the stove without the inspection cap or manifold cover in place.
tove
he
Ash Rake Handle
Inspection Manifold Cover
200 Manual Reset
High Temp Shut Off
Auger Thermodisk
Inspection Cap
Auto Reset
110 deg Normally open
Cool Down
