Chapter 4 BIOS Setup
40 Reference Manual CoreModule 430
BIOS Boot Setup Screen
Figure 4-4. BIOS Boot Setup Screen
Boot Settings Configuration
• Quick Boot – [Disabled; Enabled]
• Quiet Boot – [Disabled; Enabled]
• Add On ROM Display Mode – [Force BIOS; Keep Current]
• Bootup Num-Lock – [Off; On]
• PS/2 Mouse Support – [Disabled; Enabled; Auto]
• Wait for 'F1' If Error – [Disabled; Enabled]
• Hit 'DEL' Message Display – [Disabled; Enabled]
• Interrupt 19 Capture – [Disabled; Enabled]
• Boot From LAN – [Disabled; Used INT 18h; Used INT 19h; PnP/BEV (BBS); RPL]
• Beep Function – [Disabled; Enabled]
• OnBoard Virtual Flash FDD – [Disabled; Enabled; Diskette Write Protect]
BIOS Setup Utility
Boot Settings
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.xx (C) Copyright 1985-20xx, American Megatrends, Inc.
Boot Settings Configuration
Boot Device Priority
Main Advanced PCIPnP Boot Security Chipset Exit
CM430_BIOS_BootScreen_a
