Chapter 4
BIOS Setup
CoreModule 430
Reference Manual
37
•
PIO Mode – [Auto; 0; 1; 2; 3; 4]
•
DMA Mode – [Auto]
•
S.M.A.R.T. – [Auto; Disabled; Enabled]
•
32Bit Data Transfer – [Disabled; Enabled]
Primary IDE Slave : [Not Detected]
•
Type – [Not Installed; Auto; CD/DVD; ARMD]
•
LBA/Large Mode – [Disabled; Auto]
•
Block (Multi-Sector Transfer) – [Disabled; Auto]
•
PIO Mode – [Auto; 0; 1; 2; 3; 4]
•
DMA Mode – [Auto]
•
S.M.A.R.T. – [Auto; Disabled; Enabled]
•
32Bit Data Transfer – [Disabled; Enabled]
Secondary IDE Master : [Not Detected]
•
Type – [Not Installed; Auto; CD/DVD; ARMD]
Secondary IDE Slave : [Not Detected]
•
Type – [Not Installed; Auto; CD/DVD; ARMD]
•
Hard Disk drive Write Protect – [Disabled; Enabled]
•
IDE Detect Time Out (Sec) – [0; 5; 10; 15; 20; 25; 30; 35]
•
ATA (PI) 80Pin Cable Detection – [Host & Device; Host; Device]
•
Hard Disk Delay – [Disabled; 1 Second; 2 Second; 4 Second; 8 Second]
•
OnBoard IDE Operate Mode – [Legacy Mode; Native Mode]
•
Not Program PIO mode – [Disabled; Primary Channel; Secondary Channel]
•
Primary IDE Pin Select – [Parallel IDE; SD Card]
Remote Access Configuration
•
Remote Access – [Hotcable; Enabled]
•
Serial port number – [COM1; COM2]
Base Address, IRQ
[3F8h, 4]
•
Serial Port Mode – [115200 8, n, 1; 57600 8, n, 1; 38400 8, n, 1; 19200 8, n, 1; 09600 8, n, 1]
•
Flow Control – [None; Hardware; Software]
•
Redirection After BIOS POST – [Disabled; Boot Loader; Always]
•
Terminal Type – [ANSI; VT100; VT-UTF8]
Note: If VT-UTF8 is selected, the following item disappears from the screen.
•
VT-UTF8 Combo Key Support – [Disabled; Enabled]
•
Sredir Memory Display Delay – [No Delay; Delay 1 sec; Delay 2 sec; Delay 4 sec]
USB Configuration
•
USB Port 0, 1 – [Enabled; Disabled]
•
USB Port 2, 3 – [Enabled; Disabled]
•
USB Device – [Enabled; Disabled]
