2 Introduction
1.2 Features
SoC
 DMP Vortex86-DX2 @ max.
1 GHz
 X86 Processor Core
 Floating point unit support
 Embedded I/D L1 Cache
(16K each)
 Embedded L2 Cache (256K
4-way)
 DDR2 Interface
 GPU Control Unit (VGA, 2D
Graphic, UMA Architecture)
 Embedded 2MB Flash (BIOS
storage)
Main Memory
 1GB DDR2 Memory Down
Extension slots
 1x MiniPCIe slot with mSATA
and USB capability (3.3 V I/O)
 1x 16-bit PC/104 with full DMA
capability
Interfaces
 1x Ethernet 1GBit
 1x Ethernet 100MBit
 1x SATA (First Generation)
 1x MicroSD(HC)
 PS/2 Keyboard/Mouse
 4 x USB 2.0 ports (Nr. 4 only with
MiniPCIe extension card)
 4 x RS232/RS485
 1x LPT
 5.1 channel audio (analog &
SPDIF)
 1x VGA
 1x 18/24 Bit LVDS for displays
(alternatively to VGA)
 MISC signals: external power
button, I²C bus (3.3 V), speaker
(5 V), external reset button,
external battery connector
 8 x Analog input with 10 bit res-
olution and 100 kS/s sampling
rate
 1x 8bit GPIO-Port, usable as
TTL-UART
 1x JTAG on SIL8, 2.00 mm
pitch
 1x Power supply
Other configurations are possible. Please contact your local ADLINK
Technology representative to discuss requirements.
