42 Module Description
3.16 I2C Bus (X21)
The CM1-86DX2 offers an I2C Bus for user applications. This Bus can be used to connect other
devices which communicate over the I2C-Bus. The High-Level of this bus is 3.3V.
Table 3-26: I2C Signals (X21)
Pin I2C0, X21
1 ADC_VCC (3.3 V)
2 GND
3 ADC0
4 ADC1
5 ADC2
6 ADC3
7 ADC4
8 ADC5
9 ADC6
10 ADC7
11 I2C0_CLK
12 I2C0_DATA
