Mechanical Specifications
Vibration Step Stress
The board was subject to vibration step stress with set
points from 5 grams to 45 grams @ 20°C and vibration
increasing by 5 grams with 15 minute dwells at each
level of 2Hz to 5000Hz bandwidth
Combined Environment The board was subject to thermal cycles from -90°C to
+85°C at an average rate of 60°C per minute combined
with vibration at set points of 8, 16, 24, 32, and 40
grams from the first to the fifth thermal cycle and
10-minute dwells at each extreme temperature
Table 1-7: Mean Time Between Failures
MTBF at 25°C
TBD
MTBF at 40°C
TBD
Table 1-8: Mechanical
Dimensions (L x W) 90.6mm x 95.2mm
Height Max. 31mm on top side above PCB (including heat-
sink)
Weight
98 grams (without MiniPCIe extension card)
Mounting
4 mounting holes
ADLINK strongly recommends plastic spacers instead of metal spacers for
mounting the board. Metal spacers create the possibilities of short circuits
with the components located around the mounting holes. This can damage
the board.
