60 Using the Module
//set time counter register: 0xac, 0xab, 0xaa
outb
(( wdog_time >> 16 ) & 0xFF , 0xac ); //D23...D16
outb (( wdog_time >> 8 ) & 0xFF , 0xab ); //D15...D8
outb ( wdog_time & 0xFF , 0xaa ); //D7...D0
//set trigger: 0xa9
trig
= inb ( 0xa9 );
trig &= 0x0F ;
trig |= 0xD0 ; //0xD0 = system reset
outb ( trig , 0xa9 );
//enable wdog: 0xa8
wdog_en
= inb ( 0xa8 );
wdog_en |= 0x40 ; //bit6 = 1 --> enable WDT1
outb ( wdog_en , 0xa8 );
printf ( "Watchdog active , resetting counter , Press CTRL + C to stop resetting \ n" );
//reset timer counter : 0xa8
while( 1 )
{
reset_cntr
= inb ( 0xa8 );
reset_cntr |= 0x40 ; //bit6 = 1 --> reset counter
outb ( reset_cntr , 0xa8 );
}
return 0 ;
}
Analog Input Example
/*
########################################################################
########
# FILE: sai.c
# AUTHOR: FS for LiPPERT Adlink Technology GmbH
# DESCRIPTIONActivates the ADC and reads the selected channel once
# PARAMETERS:channel # (0 ... 7)
# COMPILENAMEsai
########################################################################
########
*/
#include
#include
#include
#include
#include
#include "../../common/pci_conf_space/pcics.c"
#define TRUE 1
// Southbridge: path defines for both functions of device 7
#define SB_PCICS0 "/proc/bus/pci/00/07.0"
#define SB_PCICS1 "/proc/bus/pci/00/07.1"
// ADC specific defines of addresses and offsets
#define ADC_BASE_ADDR 0xFE00 //user defined base address for the ADC
Please note that this source code example is provided for a system running Linux. For
other operating systems, it may be necessary to adapt the source code regarding include
files or headers and the syntax of I/O out commands because Linux is using outb(value,
address) instead of outb(address, value).
