Chapter 4 BIOS Setup
Express-IBR Reference Manual 47
 PCH Azalia Configuration
• Azalia [Disabled; Enabled; Auto]
- Azalia Docking Support [Disabled; Enabled]
- Azalia PME [Disabled; Enabled]
- Azalia Internal HDMI Codec [Disabled; Enabled]
 USB Configuration
• XHCI Pre-Boot Driver [Enabled; Disabled]
• xHCI Mode [Smart Auto; Auto; Enabled; Disabled]
- HS Port #1 Switchable [Disabled; Enabled]
- HS Port #2 Switchable [Disabled; Enabled]
- HS Port #3 Switchable [Disabled; Enabled]
- HS Port #4 Switchable [Disabled; Enabled]
- xHCI Streams [Disabled; Enabled]
• EHCI1 [Disabled; Enabled]
• EHCI2 [Disabled; Enabled]
 PCI Express Configuration
• Target Link Speed [GEN1; GEN2]
• PCIE Ports 1-4 Configuration [Four x1 Ports; One x4 Port]
• PCI Express Root Port 1 (Main Switch) [Disabled; Enabled]
• PCI Express Root Port 2 [Disabled; Enabled]
• PCI Express Root Port 3 [Disabled; Enabled]
• PCI Express Root Port 4 [Disabled; Enabled]
• PCI Express Root Port 5 [Disabled; Enabled]
• PCI Express Root Port 6 [Disabled; Enabled]
• PCI Express Root Port 7 [Disabled; Enabled]
• PCI Express Port 8 is assigned to LAN
• System Agent (SA) Configuration
System Agent Bridge Name IvyBridge
System Agent RC Version X.X.X.X
VT-d Capability Supported
 VT-d [Disabled; Enabled]
 Graphics Configuration
IGFX VBIOS Version XXXX
IGFX Frequency XXX MHz
• Primary Display [Auto; IGFX; PEG]
• Internal Graphics [Disabled; Enabled]
• GTT Size [1MB; 2MB]
• Aperture Size [128MB; 256MB; 512MB]
