Chapter 4 BIOS Setup
38 Reference Manual Express-IBR
9. Press the or keys to enter Setup.
10. Use the key to select the screen menus listed in the Opening BIOS screen.
OEM Logo Screen (Splash Screen)
The Express-IBR BIOS supports a graphical logo screen, which can be customized by the user (with
assistance by an ADLINK Sales Representative) and displayed when enabled through the BIOS Setup
Utility. The graphical image can be a company logo or any custom image the user wants to display during
the POST process.
Logo Image Requirements
Please contact your ADLINK Sales Representative for more information on OEM Logo Screen
requirements.
BIOS Setup Menus
This section provides illustrations of the six main setup screens in the Express-IBR BIOS Setup Utility.
Below each illustration is a bullet list of the screen’s submenus and setting selections. The setting selections
are presented in brackets after each submenu or menu item, and the optimal default settings are presented in
bold. For more detailed definitions of the BIOS settings, refer to the AMI Aptio TSE User Manual:
http://www.ami.com/support/doc/AMI_TSE_User_Manual_PUB.pdf .
NOTE The serial console port is not hardware protected. Diagnostic software that
probes hardware addresses may cause a loss or failure of the serial console
functions.
NOTE The Quiet Boot feature must be set to Enabled in the Boot settings of BIOS Setup for
the system to recognize the OEM Logo Screen.
Table 4-1. BIOS Setup Menus
BIOS Setup Utility Menu Item/Topic
Main BIOS, Memory, and Board information, System Language, Date, and
Time
Advanced Launch PXE OpROM, Launch Storage OpROM, Clock Spread
Spectrum, Delay Before PCI Enumeration, ACPI, Trusted Computing,
CPU, SATA, Intel TXT(LT), PCH-FW, Intel(R) Anti-Theft Technology,
AMT, USB, Hardware Monitor, Super IO, Serial Port Console, and
CPU PPM settings
Chipset PCH I/O and System Agent settings
Boot Setup Prompt Timeout, Bootup NumLock State, Quiet Boot, CSM16
Module Version, GateA20 Active, Option ROM Messages, Interrupt 19
Capture, Boot Option Priorities, and Hard Drive BBS Priorities settings
Security Setting or Changing Passwords
Save & Exit Exiting, Saving Changes, Discarding Changes, Resetting,
Restoring Defaults, Boot Override settings
