Chapter 2
Product Overview
Express-IBR
Reference Manual
9
Major Components (ICs)
lists the major integrated circuits on the Express-IBR, including a brief description of each IC.
show the locations of the major ICs.
Table 2-2. Major Integrated Circuit Descriptions and Functions
Chip Type
Mfg.
Model
Description
Function
CPU (U1)
Intel
Core i Series
(i3-3217UE,
i7-3517UE,
i7-3555LE,
i7-3612QE,
and
i7-3615QE)
1.8GHz (17W),
1.7GHz (17W),
2.5GHz (25W),
2.1GHz (35W),
and
2.3GHz (45W)
processors with up to
8MB L3 cache
Provides
integrated
processor core,
memory hub,
and graphics
hub
PCH (Platform
Controller Hub
[U3])
Intel
BD82QM77
(PCH)
I/O hub providing
Southbridge functions
(standard I/O functions)
Provides I/O
interfaces such
as USB, SATA,
and video
Hardware
Monitor (U6)
[on bottom side;
see
ON
Semiconductor
ADT7490-D
Remote Voltage and
Temperature Monitor
and Fan Controller
Provides system
thermal
protection
TPM (Trusted
Platform
Module [U7])
Atmel
AT97SC3204-
U1A90
Complete turnkey
system that integrates
industry-leading Atmel
AVR
micro-controller
architecture, Atmel
EEPROM technology,
and Atmel Security
technology on a single
chip
Provides an
integrated,
protected, non-
volatile solution
for strong public
key security,
intellectual
property
protection,
system integrity,
authentication,
and secure
communications
Board Controller
(U8) [on bottom
side; see
]
Atmel
ATMEGA168V-
10AU
Micro controller for
board functions
including I²C,
Watchdog Timer, and
LVDS
Optimizes
power
consumption
versus processor
speed
GPIO Generator
(U9)
Philips
PCA9535BS
Module providing 16
bits of GPIO expansion
for I²C/SMBus
applications
Provides
additional
digital control
lines
