12 Installation
9 OUT+ Pulse signal (+) 10 OUT- Pulse signal (-)
11 DIR+ Direction signal (+) 12 DIR- Direction signal (-)
13 EGND Ext. power ground 14 SVON Servo on output signal
15 INP In-position input signal 16 ERC Deviation counter clear output signal
17 EGND External power ground 18 E24V External power supply, +24V
19 RDY Ready input signal 20 ALM Alarm input signal
No. Name Function No. Name Function
Table 2-5: CM1-CM4 Pin Assignments: Servo Interface
